Pneumatic Collar Type Machine
Pneumatic Collar Type Machine
The Pneumatic Collar Type Machine is a versatile and efficient solution for packing powders, tea, namkeen, granules, and more. With a filling range of 25 gm to 2 kg and a speed of 25–45 pouches per minute, it ensures fast and accurate packaging. Designed with PLC-based automation, stainless steel contact parts for hygiene, and strong centre sealing for secure packs, it is ideal for food and other industries. Its robust design with a screw conveyor, 5.5 kW power, and compressed air system ensures long-lasting performance and high productivity.
| Component | Description |
|---|---|
| Application | Powder, Tea, Namkeen, Granules Etc. |
| Filling Range | 25 gm to 2 kgs. |
| Packing Speed | 25 to 45 Pouches / minutes |
| Type of Sealing | Centre Sealing |
| Pouch Dim | 100–260 mm |
| Pouch Film Material | All types of heat sealable Laminates |
| Power Requirement | 5.5 Kw, 3 Phase |
| Machine Weight | 650 kgs. + 200 kgs. Screw conveyor |
| Filling Material Contact parts | Stainless Steel AISI 304 Grade |
| Dosing System | Automatic |
| Compressed Air | 6 CFM @ 6 Bar (3HP Compressor) |
Applications
Powder
Tea
Namkeen
Granules
